E2S GNExCP7-PM Momentary Push Button Manual Call Point 手动呼叫按钮

E2S GNExCP7-PM 防爆瞬时动作按钮 Ex d 手动呼叫点具有坚固的 GRP 外壳和 316 不锈钢机构和 IP66/67 等级 – 专为最恶劣的危险环境而设计。全球范围内已通过 IECEx、ATEX、UL 和 cUL 标准认证，适用于所有 Zone 1、2、21 和 22 以及 Class I/II Div 2 安装。提供标准 DIN 导轨端子或创新的 E2S 终端板，为现场安装的 EOL 和/或系列设备提供专用连接。SIL 2 符合 IEC 61508 (2010)。

• 坚固的防腐蚀玻璃钢外壳
• 抗静电和紫外线稳定
• 防护等级 IP66/67
• 单或双开关
• 316 (A4) 不锈钢机构
• 锁定提升襟翼
• 3 x M20 电缆入口，包括 2 x 停止插头
• 系留不锈钢紧固件

Version:	Part references:	Description:
Product type:	GNExCP7PM	Momentary push button
Switch Type: [s]	S D	SPCO/SPDT DPCO/DPDT
Terminals: [t]	D P	DIN Rail 8 × SAK2.5 Termination board: 6 × 2.5mm² terminals plus 4 × EOL & Series terminals
Lift flap: [l]	L	Lift flap supplied as standard
Cable Entry Type:[e]	A B C D E F G	3 x M20x1.5mm 2 × 1/2″ NPT – adaptors 2 × 3/4″ NPT – adaptors 2 x M25x1.5mm – adaptors 1 × 1/2″ NPT – adaptor 1 × 3/4″ NPT – adaptor 1 x M25x1.5mm – adaptor
Stopping plug material: [m]	B P S	Brass Nickel Plated Brass Stainless Steel
Duty label / Equipment tag: [d]:	1 2 3 4 5 6 7	No Duty label, no Equip. tag Duty label Stainless Steel Duty label St/St + Equip. tag Duty label Metalised Polyester Duty label M. Poly. + Equip. tag Equip. tag only Special label requirement
Product version: [v]	A1	UL, cUL, IECEx, ATEX & PESO approved
Enclosure colour: [x]	R B N Y V S K M Z	Red Blue Green Yellow Red/White Yellow/Black Black Magenta Red/Black
Default variable: [u]	N	Default = N – not currently used
E.O.L.Module: [e] optional	ExxxR ED1 ExxxZ	Resistor value in Ohms e.g. E470R = 470 Ohm Diode IN4007 = ED1 Zener diode e.g. E5V1Z = 5.1V
Series Module: [s] optional	SxxxR SD1 SxxxZ	Resistor value in Ohms e.g. S1K5R = 1.5K Ohm Diode IN4007 = SD1 Zener diode e.g. S5V1Z = 5.1V
Accessories:
SP65-0001-A2 SP65-0001-A4 SP65-0002-A2 SP65-0002-A4	Pole Mount Bracket Kit 2″ St/St A2 (304) Pole Mount Bracket Kit 2″ St/St A4 (316) Sunshade – St/St A2 (304) Sunshade – St/St A4 (316)

GNExCP7PMDPL
GNExCP7PMDDL
GNExCP7PMSPL
GNExCP7PMSDL
