E2S WP7-PB 报警按钮

2021-07-31

E2S WP7-PB Dual Action Push Button Manual Call Point 报警按钮

E2S WP7-PB 双动扭转按钮手动呼叫点具有坚固的 GRP 外壳,带有 316 不锈钢机构和 IP66/67 等级 – 专为在最恶劣的环境中可靠启动而设计。SIL2 符合 IEC 61508 (2010)。紫外线稳定的玻璃纤维增​​强聚酯外壳可以承受海上和海上安全区域安装的严酷环境。扩展的工作温度范围、不锈钢机构和闭锁提升翻板确保 WP7-PB 提供可靠的双动扭转和推动开关激活。

  • 坚固的防腐蚀玻璃钢外壳
  • 抗静电和紫外线稳定
  • 防护等级 IP66/67
  • 单或双开关
  • 316 (A4) 不锈钢机构
  • 3 x M20 电缆入口,包括 2 x 停止插头
  • 系留不锈钢紧固件
Version: Part references: Description:
Product type: WP7PB Dual action push button
Switch Type: [s] S
D
SPCO/SPDT
DPCO/DPDT
Terminals: [t] D
P
DIN Rail 8 × SAK2.5
Termination board: 6 × 2.5mm² terminals plus 4 × EOL & Series terminals
Lift flap: [l] L Lift flap supplied as standard
Cable Entry Type:[e] A
B
C
D
E
F
G
3 x M20x1.5mm
2 × 1/2″ NPT – adaptors
2 × 3/4″ NPT – adaptors
2 x M25x1.5mm – adaptors
1 × 1/2″ NPT – adaptor
1 × 3/4″ NPT – adaptor
1 x M25x1.5mm – adaptor
Stopping plug
material: [m]
N
B
P
S
Nylon
Brass
Nickel Plated Brass
Stainless Steel
Duty label / Equipment tag: [d]: 1
2
3
4
5
6
7
No Duty label, no Equip. tag
Duty label Stainless Steel
Duty label St/St + Equip. tag
Duty label Metalised Polyester
Duty label M. Poly. + Equip. tag
Equip. tag only
Special label requirement
Product version:
[v]
A1 CE marked SIL2 compliant
Enclosure colour: [x] R
B
N
Y
V
S
K
M
Z
Red
Blue
Green
Yellow
Red/White
Yellow/Black
Black
Magenta
Red/Black
Default variable: [u] N Default = N – not currently used
E.O.L.Module: [e]
optional
ExxxR
ED1
ExxxZ
Resistor value in Ohms e.g. E470R = 470 Ohm
Diode IN4007 = ED1
Zener diode e.g. E5V1Z = 5.1V
Series Module: [s]
optional
SxxxR
SD1
SxxxZ
Resistor value in Ohms e.g. S1K5R = 1.5K Ohm
Diode IN4007 = SD1
Zener diode e.g. S5V1Z = 5.1V
Accessories:
SP65-0001-A2
SP65-0001-A4
SP65-0002-A2
SP65-0002-A4
Pole Mount Bracket Kit 2″ St/St A2 (304)
Pole Mount Bracket Kit 2″ St/St A4 (316)
Sunshade – St/St A2 (304)
Sunshade – St/St A4 (316)

WP7PBDPN
WP7PBDDN
WP7PBSPN
WP7PBSDN
